BMF CRANES

BMF range of cranes includes models with reach from 4,3 up to 10 meters. Product names of BMF cranes indicate maximum reach

BMF430

Forestry crane with total reach of 4.3 meters

Maximum reach, m 4,3
Lifting torque, kNm, gross
29
Lifting power on 4m without grapple and rotator, kg (3m) 620
Lifting power of full reach without grapple and rotator, kg 420
Grapple, m2 0,15
Rotator 3t
Slewing torque, kNm 4,9
Slewing cylinders, pcs 2
Boom rotation, ° 360
Working pressure, bar  190
Hydraulic pump capacity, l/min 30-60
Support leg A
Wide angle +
Telescope-
Total weight without leg, kg 395

* Technical data is subject to change without prior notice.
** Model year 2023

BMF540

Wide angle forestry crane with total reach of 5.4 m

Maximum reach, m 5,4
  • Lifting torque, kNm, gross
30
Lifting power on 4m without grapple and rotator, kg 550
Lifting power of full reach without grapple and rotator, kg 390
Grapple, m2 0,15
Rotator 3t
Slewing torque, kNm 4,9
Slewing cylinders, pcs 2
Boom rotation, ° 360
Working pressure, bar  200
Hydraulic pump capacity, l/min 30-60
Support leg A
Wide angle +
Telescope +
Total weight without leg, kg 550

*Technical data is subject to change without prior notice.
** Model year 2023

BMF650

Timber crane with a telescope and maximum reach of 6.5 m.

Maximum reach, m 6.5
  • Lifting torque, kNm, gross
48
Lifting power on 4m without grapple and rotator, kg 840
Lifting power of full reach without grapple and rotator, kg 510
Grapple, m2 0.2
Rotator 3t / 4t
Slewing torque, kNm 11
Slewing cylinders, pcs 4
Boom rotation, ° 360
Working pressure, bar 200
Hydraulic pump capacity, l/min 30-60
Support leg A / FD
Wide angle +
Telescope +
Total weight without leg, kg 686

* Technical data is subject to change without prior notice.
** Model year 2023

BMF720

Timber crane with wide-angle joint and telescope, max. reach 7.2 m

Maximum reach, m 7.2
  • Lifting torque, kNm, gross
60
Lifting power on 4m without grapple and rotator, kg 1100
Lifting power of full reach without grapple and rotator, kg 580
Grapple, m2 0.2 / 0.24
Rotator 3t / 4t
Slewing torque, kNm 14
Slewing cylinders, pcs 4
Boom rotation, ° 370
Working pressure, bar  200
Hydraulic pump capacity, l/min 30-60
Support leg A / FD
Wide angle +
Telescope +
Total weight without leg, kg 710

*Technical data is subject to change without prior notice.
** Model year 2023

BMF750

Forestry crane incl. wide angle joint, telescope and 7.5 m max. reach


BMF750

BMF750 HP
Maximum reach, m 7,5 7,5
  • Lifting torque, kNm, gross
76
 86
Lifting power on 4m without grapple and rotator, kg 1410 1570
Lifting power of full reach without grapple and rotator, kg 750 830
Grapple, m2 0.24 / 0.27 0.24 / 0.27
Rotator 4t 4t
Slewing torque, kNm 17 20.5
Slewing cylinders, pcs 4 4
Boom rotation, ° 370 370
Working pressure, bar  200 225
Hydraulic pump capacity, l/min 50-100  50-100
Support legFD FD
Wide angle + +
Telescope + +




*Technical data is subject to change without prior notice.
** Model year 2023

BMF800HD

BMF800 is ultimate heavy-duty solution for professional use

 BMF800HD BMF800HD+
Maximum reach, m 8,0 8,0
  • Lifting torque, kNm, gross
119
 128
Lifting power at 4 m w/o
 grapple and rotator, kg
2010 2250
Lifting power of full reach w/o
 grapple and rotator, kg
1000 1120
Grapple, m2 0,27 / 0,37  0,27 / 0,37
Rotator 6t 6t
Slewing torque, kNm 35 40
Slewing cylinders, pcs 4 4
Boom rotation, ° 385 385
Working pressure, bar 230 230
Hydraulic pump capacity, l/min 100-150  100-150
Support leg- -
Wide angle + +
Telescope+ +

* Technical data is subject to change without prior notice.
** Model year 2023

BMF850

Crane wide-angle joint, double telescope and max. reach of 8.5 m.

 BMF850BMF850HP
Maximum reach, m 8.5 8.5
  • Lifting torque, kNm, gross
76
 86
Lifting power on 4m without grapple and rotator, kg 1350 1520
Lifting power of full reach without grapple and rotator, kg 630 710
Grapple, m2 0.24 / 0.27  0.24 / 0.27
Rotator 4t 4t
Slewing torque, kNm 17 20,5
Slewing cylinders, pcs 4 4
Boom rotation, ° 370 370
Working pressure, bar  200 225
Hydraulic pump capacity, l/min 50-100   50-100
Support legFD FD
Wide angle + +
Telescope2x 2x
Total weight without leg, kg 1095 1095



* Technical data is subject to change without prior notice.
** Model year 2023

BMF905

Crane with max reach of 9.05 m, wide-angle joint & double telescope

 BMF905BMF905HP
Maximum reach, m 9.05 9.05
  • Lifting torque, kNm, gross
76
 86
Lifting power on 4m without grapple and rotator, kg 1210 1370
Lifting power of full reach without grapple and rotator, kg 520 590
Grapple, m2 0.24 / 0.27 0.24 / 0.27
Rotator 4t 4t
Slewing torque, kNm 20,5 20,5
Slewing cylinders, pcs 4 4
Boom rotation, ° 370 370
Working pressure, bar 200 225
Hydraulic pump capacity, l/min 50-100
  50-100
Support legFD FD
Wide angle + +
Telescope2x 2x
Total weight without leg, kg 1130 1130


       
* Technical data is subject to change without prior notice.
** Model year 2023

BMF1000HD

Powerful crane with wide-angle, double telescope, max reach 10 m

 BMF 1000HDBMF 1000HD+
Maximum reach, m 10.0 10.0
  • Lifting torque, kNm, gross
119
 128
Lifting power on 4m without grapple and rotator, kg 1880 1960
Lifting power of full reach without grapple and rotator, kg 710 760
Grapple, m2 0.27 / 0.37   0.27 / 0.37
Rotator 6t 6t
Slewing torque, kNm 35 40
Slewing cylinders, pcs 4 4
Boom rotation, ° 385 385
Working pressure, bar  230 230
Hydraulic pump capacity, l/min 100-150 100-150
Support leg -  -
Wide angle+ +
Telescope+ +

* Technical data is subject to change without prior notice.
** Model year 2023
