TRAILERS BMF

The first number in easch trailer product name marks the load capacity and last trailer beams (single/double)

BMF 6T2

Two wheeled platform trailer up to 6 t capacity

Loading capacity, kg6000
Total length, mm
4895
Length of loading area3000
Total width with standard wheels, mm2030
Wheels11,5/80-15,3
400/60-15,5
Chassis, mm60x120x6
Axels70x70-6
Loading area, m²1,3
Drawbar cylinders, pcs -
Drawbar angle to sides, ± ° -
Clearence, mm 470
Support leg A


BMF 7T1

Trailer for the forestry with up to 7 t capacity

Loading capacity, kg7000
Total length, mm
4425
Length of loading area2800
Total width with standard wheels, mm2005
Wheels11,5/80-15,3
400/60-15,5
Chassis, mm140x140x6
Axels60x60-6
Loading area, m²1,45
Drawbar cylinders, pcs -
Drawbar angle to sides, ± ° -
Clearence, mm555
Support leg A


BMF 8T1

Forestry trailer: one-beam designed with 8t capacity

Loading capacity, kg8000
Total length, mm
5660
Length of loading area3380
Total width with standard wheels, mm2170
Wheels400/60-15,5
500/50-17
520/50-17
Chassis, mm160x160x8
Axels60x60-6
Loading area, m²1,95
Drawbar cylinders, pcs1-
Drawbar angle to sides, ± °40
Clearence, mm575
Support leg-


BMF 8T2

Forestry trailer with two beams up to 8t capacity

Loading capacity, kg8000
Total length, mm
5955
Length of loading area3575
Total width with standard wheels, mm2120
Wheels400/60-15,5
500/50-17
520/50-17
Chassis, mm2x(200x100x6)
Axels60x60-6
Loading area, m²2,2
Drawbar cylinders, pcs1
Drawbar angle to sides, ± °40
Clearence, mm565
Support leg-


BMF 9T1

Forestry trailer: one beam designed with 9t capacity

Loading capacity, kg9000
Total length, mm
6160
Length of loading area3850
Total width with standard wheels, mm2170
Wheels400/60-15,5
500/50-17
520/50-17
Chassis, mm160x160x8
Axels70x70-6
Loading area, m²1,95
Drawbar cylinders, pcs2
Drawbar angle to sides, ± °40
Clearence, mm575
Support leg-


BMF 9T2

Forest trailer with two beams and up to 9t capacity

Loading capacity, kg9000
Total length, mm
6180
Length of loading area3800
Total width with standard wheels, mm2120
Wheels400/60-15,5
500/50-17
520/50-17
Chassis, mm2x(200x100x6)
Axels70x70-6
Loading area, m²2,2
Drawbar cylinders, pcs2
Drawbar angle to sides, ± °40
Clearence, mm565
Support leg-


BMF 10T2

Forestry machine – a two beam trailer with up to 10t payload

Loading capacity, kg10000
Total length, mm
6380
Length of loading area4000
Total width with standard wheels, mm2120
Wheels400/60-15,5
500/50-17
520/50-17
Chassis, mm2x(200x100x6)
Axels70x70-6
Loading area, m²2,2
Drawbar cylinders, pcs2
Drawbar angle to sides, ± °40
Clearence, mm565
Support legA / FD



BMF 10T2 Pro

Two beam trailer and up to 10t capacity

Loading capacity, kg10000
Total length, mm
6380
Length of loading area4000
Total width with standard wheels, mm2120
Wheels400/60-15,5
500/50-17
520/50-17
Chassis, mm2x(200x100x6)
Axels70x70-6
Loading area, m²2,2
Drawbar cylinders, pcs2
Drawbar angle to sides, ± °40
Clearence, mm565
Support legA / FD



BMF 11T1

Forestry machine – one beam trailer with up to 11t payload

Loading capacity, kg11000
Total length, mm
6185
Length of loading area3870
Total width with standard wheels, mm2275
Wheels400/60-15,5
500/50-17
520/50-17
Chassis, mm200x200x8
Axels70x70-6
Loading area, m²2,3
Drawbar cylinders, pcs2
Drawbar angle to sides, ± °40
Clearence, mm580
Support leg-


BMF 12T2 Pro

Two-beam trailer with up to 12t capacity

Loading capacity, kg12000
Total length, mm
6600
Length of loading area4200
Total width with standard wheels, mm2185
Wheels400/60-15,5
500/50-17
520/50-17
Chassis, mm2x(200x100x6)
Axels70x70-6
Loading area, m²2,45
Drawbar cylinders, pcs2
Drawbar angle to sides, ± °40
Clearence mm565
Support legA / FD



BMF 14T2 Pro

Timber trailer with two-beam trailer and  up to 14t capacity

Loading capacity, kg14000
Total length, mm
6600
Length of loading area4200
Total width with standard wheels, mm2435
Wheels550/45-22,5
Chassis, mm2x(200x100x6)
Axel80x80-8
Loading area, m²2,45-2,8
Drawbar cylinders, pcs2
Drawbar angle to sides, ± °40
Clearence, mm670
Support legA / FD


BMF 17T2 Pro

Forestry trailer 17T2 Pro with up to 17t payload

Loading capacity, kg17000
Total length, mm
6920
Length of loading area4200
Total width with standard wheels, mm2520
Wheels550/45-22,5
600/50-22,5
Chassis, mm2x(200x100x8)
raex400(8mm)
Axels90x90-8
Loading area, m²2,9-3,4
Drawbar cylinders, pcs2
Drawbar angle to sides, ± °40
Clearence, mm695
Support legFD
